Inside | Min Inside | Max Inside | Min Outside | Max Outside | Working pressure | Bend radius |
|---|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | mpa | mm |
| 5 | 4.8 | 5.5 | 12.7 | 13.7 | 21 | 75 |
| 6.3 | 6.4 | 7.2 | 14.3 | 15.3 | 21 | 85 |
| 8 | 7.9 | 8.7 | 16.7 | 17.6 | 15.7 | 100 |
| 11 | 10.3 | 11.1 | 18.9 | 20.0 | 14 | 115 |
| 12.5 | 12.7 | 13.7 | 22.8 | 24.0 | 12.2 | 140 |
| 16 | 15.9 | 17.0 | 26.8 | 28.0 | 10.5 | 165 |
| 22 | 22.2 | 23.3 | 30.6 | 32.2 | 5.6 | 185 |
| 29 | 28.6 | 29.8 | 37.3 | 38.9 | 4.3 | 230 |
| 35 | 34.9 | 36.1 | 43.7 | 45.2 | 3.5 | 265 |
| 46 | 46.0 | 47.2 | 55.2 | 57.6 | 2.4 | 335 |
| 60 | 60.3 | 61.9 | 71.8 | 74.2 | 2.4 | 610 |
| 78 | 76.2 | 77.8 | 89.3 | 91.7 | 1.4 | 840 |
